- Bends 10 gauge mild steel and 12 gauge stainless steel or lighter.
- 10 feet (120”) bending length.
- Maximum bend angle of 135°.
- Industrial-grade hydraulic systemdoes all of the following:
- Clamps the material at the fingers,
- Lifts the bend eaf to the pre-set bend angle,
- Opens the beam when the bend is complete.
- Hydraulically-driven bend leaf.
- 5 hp motor runs on 220-volt three-phase power.
- Made using only the most durable and high-quality electrical components.
- Includes 26 hardened fingers in assorted sizes (6 of 3", 4 of 4", 10 of 5", and 6 of 6"); adjust them for different box and pan applications.
- Adjustable auto-stop: just dial in the bend degree when using the hydraulic bending brake in manual or semi-automatic mode.
- Variable bend speed and clamping pressure adjustment give you control over the material.
- You can operate the machine by toggle from the console, or by using the foot pedal controls.
- Semi-automatic bending mode with foot pedal control will increase productivity, reduce operator effort, and streamline production runs.
- Material thickness adjustment enables you to take on many gauges of sheet metal and easily switch between them.
- Greaseable joints and filtered hydraulic system enable this sheet metal brake to work smoothly for years.
- Electro-welded steel frame, with massive truss rods, minimizes deformation when bending at full capacity.
- Extra-rigid base design supports the weight of heavier materials.
What's in The Box
- BB-12010H - Hydraulic Sheet Metal Brake
- Owner's Manual
- 1 Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
|Power||220V / 3-phase|
|Min Reverse Bend||.984"|
|Thickness (SS)||10 ga. (12 ga.)|
|Bend Angle||0 – 135°|
|Finger Sizes||3" – 4" – 5" – 6"|
|Dimensions (Inches)||158 x 44 x 70|
