Sku | PM23150RK |
Brand | Powermatic |
Motor Voltage | 230V |
Motor Current (Amp) | 14.5 Amp |
Recommended Circuit Size (Amp) | 20 Amp |
Motor Power (HP) | 3 HP |
Motor Phase | 1 |
Dust Collection (Cfm) | 400 Cfm |
Dust Port Outside Diameter (In.) | 4 In. |
Style (Type) | Cabinet |
Blade Diameter (In.) | 10 In. |
Arbor Diameter (In.) | 5/8 In. |
Arbor Speed (Rpm) | 4500 Rpm |
Maximum Depth of Cut at 90 Degrees (In.) | 3-1/8 In. |
Maximum Depth of Cut at 45 Degrees (In.) | 2-1/8 In. |
Maximum Diameter of Dado (In.) | 8 In. |
Maximum Width of Dado (In.) | 13/16 In. |
Table in Front of Saw Blade at Maximum Depth of Cut (In.) | 11-1/4 In. |
Maximum Rip Right of Blade (In.) | 50 In. |
Maximum Rip Left of Blade (In.) | 13-1/2 In. |
Table Type | Cast Iron |
Table Height from Floor (In.) | 35 In. |
Table Size (In.) | 22 x 30-1/2 In. |
Table Size with Extensions (In.) | 42 x 30-1/2 In. |
Table T-Slot (In.) | 3/4 x 3/8 In. |
Shipping Weight (lbs) | 724 lbs |
